Installation
Instructions
31-46148
224D2601P001
06-08 JR
36" Built-In All-Refrigerators
and All-Freezers
monogram.com
Page view 0
1 2 3 4 5 6 ... 23 24

Summary of Contents

Page 1 - Instructions

InstallationInstructions31-46148224D2601P00106-08 JR36" Built-In All-Refrigerators and All-Freezersmonogram.com

Page 2 - CONTENTS

Installation Instructions10DO NOT, UNDER ANYCIRCUMSTANCES, CUT OR REMOVE THE THIRD (GROUND) PRONGFROM THE POWER CORD.DO NOT USE AN ADAPTER PLUG TO CON

Page 3 - Design Guide

Installation Instructions11STEP 3 INSTALL SIDE PANELSSkip this step when not using side panelsIf you are using 1/4" side panels, they should be

Page 4

Installation Instructions12Two Additional Hole Locations at Ends of BracketsCenterWall BracketLine On WallWall StudsSTEP 4 INSTALL ANTI-TIP BRACKETWA

Page 5

Install Screws and Bolts:• Have someone hold the wall bracket centered in place with each of the holes aligned with the correct opening in the bracket

Page 6

Installation Instructions14STEP 4 INSTALL ANTI-TIP BRACKET(cont.)Remove Grilles for Access to Power Cord and Anti-tipLocking HooksFresh Food Unit• Op

Page 7

15Installation InstructionsSTEP 5 LEVEL UNITAll models have 4-point leveling. The front is supportedby leveling legs; the rear is supported by adjust

Page 8

Installation Instructions16STEP 6 SECURE UNIT TO WALL• The “L” rods can be found in the upper left and rightcorners of the unit in the access compart

Page 9

STEP 7 ADJUST DOOR SWINGNOTE: This refrigerator has a 2-position door stop.When space does not allow the door to swing openfully to 130°, you may cha

Page 10 - Installation Instructions

18Installation InstructionsSTEP 9 INSTALL FRAMED PANELS(TRIMMED MODELS ONLY)• There are two sets of holes in the handle side trim.Replace the handle

Page 11

STEP 9A INSTALL OVERLAY PANELS• There are two sets of holes in the handle side trim.Replace the handle side trim by installing the originalscrews in

Page 12 - WARNING: ANTI-TIP PRECAUTIONS

Safety InformationSkill Level - Installation of this product requires basicmechanical, carpentry and plumbing skills. Properinstallation is the respon

Page 13

Installation Instructions20STEP 10 CONNECT WATER SUPPLY(FREEZER MODELS ONLY)• Locate and bring the tubing to the front of the cabinet.• Turn the wate

Page 14

21Notes

Page 16

23Notes

Page 17

GE Consumer & IndustrialAppliances General Electric Company Louisville, KY 40225ge.comPrinted in the United StatesNOTE: While performing installat

Page 18

Design Guide336" Frame to Frame Width*84" FromFloor toTop Frame35"Case Width*83-1/2" atRear25-3/8" Framed Models25-3/4"

Page 19

Design Guide4These units are equipped with a 2-position door stop.The factory set 130° door swing can be adjusted to 90°if clearance to adjacent cabin

Page 20

Design Guide5Top View130° DOOR SWING(factory setting)Scale 1:1Frameless Cabinets: The case trim overlaps cabinets at the top and sides.Therefore, fram

Page 21

Design Guide61/4"1/2"3/4"1"1-1/4"1/4"1/2"3/4"1"1-1/4"1-1/2"23-7/8"From Rear of UnitCabinet

Page 22

Design Guide7CUSTOMIZATION BASICS: Framed Or Overlay Panels, Custom Handles and Accessory KitsOverlay panelsYou may also choose to install custom over

Page 23

Design Guide81/4" FRAMED PANEL DIMENSIONSIf you choose to install framed panels, they must be cut tothe dimensions shown. The panels will slide i

Page 24 - 31-46148

*84"2-9/16"24"*3" to 4"3/16"1-7/8"Design Guide9SIDE PANELSSide panels must be used whenever the sides of the unit w
